Launched in 2017, the Cobra-S 800 is our original and most popular high-speed spectrometer for near infrared OCT laboratory research. It is used in research applications in ophthalmology and materials processing as well as more specialized techniques like polarization-sensitive OCT (PS-OCT) and optical coherence elastography (OCE).
Widely cited in literature, we continuously marvel how this enabling technology is helping academics push the boundaries of OCT research.
Bandwidth (typ.)
Imaging Depth (typ.)
1.5 mm
Spectral Resolution (typ.)
0.06 nm
Axial Resolution (typ.)
Weight (approx.)
* Lower-speed configurations available on extended lead-time.
The Cobra-S 800 offers superior roll-off performance as compared to traditional OCT spectrometers, as can be seen in this comparison of signal with imaging depth. With less roll-off, much deeper structures can be imaged clearly than is expected of typical 800 nm imaging.
Compatible with Wasatch Photonics’ SDKs for rapid data access and control in development environments (e.g., C++, LabVIEW, MATLAB).
WAVELENGHTH BAND (nm)
CENTER WAVELENGHTH (nm)
BANDWIDTH (nm)
CAMERA SPEED (kHz)
Up to 130 kHz (USB 3.0)
or up to 250 kHz
(Camera Link only)
O = Organic
[Blank] = Ceramic
(default/standard)
CS-λλλ-λcλcλc-λBWλBW-SS-CAM-CONN-X
